AU-XVDP

The AutronX AU-XVDP Battery Video Door Phone delivers high-definition 1920×1080 resolution with a 166° wide-angle lens and IR night vision (6×850mm LEDs). This wireless system operates on dual 18650 or 21700 batteries, providing 3-12 months of standby time with ultra-low power consumption (20μA standby).

Featuring PIR motion detection and instant remote wake-up (<1 second), it ensures 24/7 monitoring with automatic day/night mode switching. The device supports micro SD storage (up to 128GB) and crystal-clear two-way audio with noise cancellation over 2.4GHz Wi-Fi (IEEE 802.11b/g/n).

Download Datasheet
Download Catalogue

Extended Battery Life

6-12 month operation (5200-10400mAh options)

Wide-Angle Monitoring

166° field of view with IR night vision

Smart Motion Alerts

PIR detection with instant phone notifications

Technical Specifications

ModelAX-BT-201
Resolution1920×1080 (1080P)
Viewing Angle166°
Night Vision6×850mm IR LEDs
Wi-Fi2.4GHz (802.11b/g/n)
Battery Options2×18650 (5200mAh) or 2×21700 (10400mAh)
StorageMicro SD (8/16/32GB supported, max 128GB)
Power ConsumptionStandby: 20μA / Active: 170mA
Operating Temp.-10°C to +50°C

Key Functional Modes

Security Monitoring

24/7 surveillance with smart detection.

  • PIR motion-triggered alerts
  • Auto IR-CUT day/night switching
  • Instant remote wake-up (<1s)
Battery Saver

Optimized power management.

  • 20μA ultra-low standby
  • 6-12 month battery life
  • DC 5V recharge option
HD Communication

Premium audio/video quality.

  • 1080P@30fps streaming
  • Noise-cancelling two-way audio
  • 166° wide-angle coverage

Installation Guide

  • Battery Installation: Insert 2×18650/21700 batteries in slot.
  • Mounting: Secure via mounting port (avoid metal surfaces).
  • Wi-Fi Setup: Connect to 2.4GHz network via app.
  • Storage: Insert formatted micro SD card (FAT32).
  • Testing: Verify PIR sensitivity and wake-up response.
  • Charging: Use 5V/1A adapter via USB interface when needed.

Troubleshooting & FAQs

1
Battery drains faster than expected.
Disable unnecessary features like continuous recording.
2
Motion alerts not triggering.
Adjust PIR sensitivity in app settings.
3
Night vision not activating.
Check IR LED functionality in dark environments.
4
SD card not recognized.
Format to FAT32 (max 128GB supported).
