4-Wire Tubular Motor
Smart, Energy Saving Detection for your spaces
4-Wire Tubular Motor
The 4-Wire Tubular Motor operates at 100-230V AC with a rated power of 115W and increased speed of 28 RPM. Designed for integration with automation systems, it maintains the same reliable 6Nm torque and 10Kg load capacity as its 3-wire counterpart.
This IP44-rated motor features patented quiet technology (30dB operation) and a double-sided brake structure. Its 4-wire configuration enables seamless compatibility with smart home automation while reducing vibration noise through its unique power output design
Automation Ready
4-wire design for smart system integration.
Quiet Performance
Patented technology for 30dB operation.
High-Speed Operation
28 RPM speed for faster cycle times.
Technical Specifications
| Operating Voltage | 100-230V/AC | 50/60Hz |
|---|---|
| Rated Power | 115W |
| Frequency | 433.92 MHz |
| Rated Speed | 28 RPM |
| Rated Torque | 6Nm |
| IP Rating | IP44 |
| Max. Load | 10Kg |
| Control | Automation Compatible |
Key Functional Modes
Automation Mode
Seamless integration with smart control systems.
- 4-wire control interface
- Compatible with major automation platforms
- Remote operation capability
High-Speed Operation
Efficient 28 RPM performance.
- Faster cycle times
- Maintained 6Nm torque
- 10Kg load capacity
Quiet Technology
Patented noise reduction features.
- 30dB operation
- Vibration-dampening design
- Double-sided brake
Installation Guide
- Power Off: Disconnect all power before installation.
- Load Verification: Confirm load ≤10Kg.
- Wiring: Connect 4-wire configuration per automation specs.
- Mounting: Secure with appropriate brackets.
- System Integration: Pair with automation controller.
- Testing: Verify speed and brake function.
